Description
The ideal PV Module for all applications that use the highest quality of PV Cells, in-house encapsulants, and backsheets. Suitable for utility, rooftop, and other general applications.
Key Features
- Made in India.
- Positive power tolerance.
- Highly reliable anti-reflective coated glass.
- Extreme weather resilience
- Wind speed – 2400Pa.
- Snow load – 5400Pa.
- IP 68 junction box with 3 bypass diodes
- PID Resistant
- High power density
- Positive power tolerance
- 3.2mm Thick low iron tempered
Quality & Safety
- IEC 61215, IEC 61730 and 61853 compliant.
- UL 1703 compliant.
- ISO: 9001-2015 Certified Manufacturing Facility.
Warranty
- Limited Power Output Warranty – 25 Years.
- Product Warranty – 10 Years.
Electrical Characteristics
- Peak Power, Pmax (W) – 545W
- Open circuit voltage, Voc (V) – 49.97.
- Short circuit current, lsc (A) – 13.74V.
- Voltage at Maximum power, Vmp (V) – 41.98V
- Current at Maximum power, Imp (A) – 12.99A.
- Module Efficiency (%) – 20.99%.
Mechanical Parameters
- Module dimension – 2284mm X 1137mm X 35mm
- Weight: 28.7 Kg.
- No. of Cells – 140.
- Solar cell Type – Mono crystalline cells.
- Front Cover – 3.2mm thick low iron tempered glass.
- Frame Material – Anodized Aluminium Alloy.
- Junction Box – IP68 Split junction box
with 3 bypass diodes - PV Connectors: MC4 Compatible
